The Poynting OMNI-A0085-V2 broadband antenna provides a strong 2G, 3G, or 4G/LTE connection and high transfer speeds for your broadband modem or router. The antenna is vertically polarized and omnidirectional. The antenna can be used directly on equipment that has an SMA male connector. The antenna's knuckle base allows it to be adjusted to multiple angles.
Specifications Poynting Panel Mount LTE Antenna:
Frequencies 690 – 960, 1710 – 2700 MHz
Gain (Max): 3.8 dBi (3 dBi nominal)
Frequency: 690 – 960 and 1710 – 2700 MHz
VSWR @ 690 – 960 MHz: 2.6 across 50% of entire band
VSWR @1710 – 2700 MHz: < 2 across 60% of entire band
Feed Power Handling: 4 W
Nominal Input Impedance: 50 Ohm (nominal)
Polarisation: linear (vertical or horizontal)
Connector: SMA male
Dimensions (L x W x D): 210 mm x 20 mm
Weight: 0.06 kg
Color: black
Operating Temperature: -20°C to +70°C
Thermal Shock: -20°C to +70°C: 10 cycles
Shock: 40 G at 10 msec
