The Kemot PROsinus-800 combines a backup power supply, pure sine wave inverter and battery charger in one unit.
Used with an external 12 V battery, it provides 230 V AC backup power during mains failure. The pure sine wave output makes it suitable for sensitive electronics and various inductive loads such as pumps and heating equipment.
Operating modes:
- Backup power supply with battery charging
- Battery charger
- 12 V DC to 230 V AC inverter
Product specifications:
- Brand: Kemot
- Model: PROsinus-800
- Part number: URZ3405
- EAN: 5901890013093
- Product type: UPS / inverter / battery charger
- Apparent power: 800 VA
- Rated continuous power: 500 W
- Battery voltage: 12 V DC
- External battery required: yes
- Battery included: no
- Maximum battery voltage: 15 V DC
- Supported battery capacity: approx. 50–200 Ah
- Recommended battery capacity: approx. 80 Ah
- AC input voltage: 190–260 V AC
- Input frequency: 45–60 Hz
- AC output on mains: 230 V AC ±5%
- Inverter output: 230 V AC ±3%
- Output frequency: 50/60 Hz ±0.5 Hz
- Output waveform: pure sine wave
- DC-to-AC efficiency: ≥85%
- Maximum battery charging current: 15 A
- Estimated charging time: approx. 4–14 hours depending on battery capacity
- Transfer time: ≤4 ms
- Operating temperature: 0 to 40 °C
- Relative humidity: 10–90%
- Dimensions: approx. 145 x 180 x 240 mm
- Weight: approx. 4.6 kg
- Gross packaged weight: approx. 5 kg
- Package dimensions: approx. 290 x 190 x 225 mm
- Installation: freestanding / tower
- Colour: white
- Fixed phase position: yes
Protection features:
- Overload protection
- Short-circuit protection
- Overvoltage protection
- Undervoltage protection
Suitable for:
- Heating boilers
- Gas boilers
- Pellet heating systems
- Circulation pumps
- Heating controls
- Water pumps
- Computers
- Monitors
- Consumer electronics
- Office equipment
- Sensitive electronics
- Inductive equipment within the rated capacity
Important:
- An external 12 V battery is required for backup operation.
- Battery is not included.
- Rated continuous output is 500 W.
- Motors, pumps and compressors can draw substantially higher current during startup.
- Check peak and starting power before connecting equipment.
Included:
- 1 x Kemot PROsinus-800
- Battery connection leads according to standard package
- Documentation
Not included:
- 12 V battery
- Additional battery cables
- Additional external fuse where required
