JL Audio M600/6-24V - 6 kanaals versterker for 24V systemen. 100 Watt aan elk from de zes kanalen bij 2 ohm (14.4V, 1% THD), 75 W x 8 @ 4 Ω - 14.4V. De M600 heeft a 12 dB / octaaf-filter for elke kanaal die kan worden geconfigureerd als a laagdoorlaat- or hoog doorlaat filter and heeft a continu variabele afsnijfrequentieselectie from 50-500 Hz.
Specifications JL Audio M600/6-24V:
Frequency Response 12 Hz - 22 kHz (+0, -1dB)
S/N Ratio, referred to highest rated power >104 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W >84 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
Damping Factor @ 4 Ω >150 / 50 Hz
Damping Factor @ 2 Ω >75 / 50 Hz
THD+N @ Rated Power <1% @ 2 Ω per Ch.
Input Voltage Range @ RCA Inputs Switchable from 200 mV - 2 V RMS (Low) to 800 mV - 8 V RMS (High)
Min.Copper Power / Ground Wire Gauge 4 AWG wire
Fuse Rating 80 A (AFS, AGU or MaxiFuse™)
Signal processing:
Filter Mode(s) Low-Pass or High-Pass
Filter Slope(s) 12 dB/octave
Filter Frequency Range 50 Hz - 500 Hz
Detented, Calibrated Filter Freq. Potentiometers Yes
Filter Defeat Function Yes
Remote Level Control Optional (HD-RLC)
Remote Level Modes 2 or 4 or All Channels
Channel Input Mode Switch Yes (2/4/6/8 ch.)
Pass-Through Preamp Output None
Source Channel Selection for PreOuts N/A
Handleiding JL Audio M600/6-24V.
