The Em-Trak B330 AIS offers a unique combination of toughness and performance that is ideal for use in harsh commercial marine environments. This AIS is dustproof and waterproof and is also resistant to shocks and vibrations. The B330 AIS has a built-in GPS and WiFi antenna, and it is also possible to connect an external GPS antenna. The software to program it is included in the box.
With the WiFi function, devices such as iPads or other mobile devices can connect wirelessly to the B330 and receive AIS, GPS, and multiplexed NMEA data for use in mobile apps such as iNavX, iSailor, and more.
Features of the Em-trak B330 AIS:
Fully certified AIS class B
Waterproof - IPx6 and IPx7 certified
Shock and vibration resistant
Low energy consumption
Receives and processes all AIS message types
Silent mode feature
Integrated WiFi
Multiple interfaces: NMEA0183, NMEA2000 provides plug and play compatibility with most display systems
Internal GPS antenna, an external GPS antenna is optional
Specifications Em-trak B330:
Dimensions 140 x 100 x 50 mm (D x W x H)
Weight 280 grams
USB connection
WiFi antenna
NMEA2000
IEC61162-1 (NMEA0183) output, 38400 baud
IEC61162-1 (NMEA0183) input, 4800 baud
Power supply 12 or 24V DC
Power consumption 150mA @12VDC, <2W
Transmitter x 1 / Receiver x 2
Frequency: 156.025 to 162.025 MHz in 25KHz steps
Transmission power: 2W
