The Rebelcell 12.6V4A XT60 lithium charger is designed for safe and automatic charging of suitable Rebelcell 12V AV lithium batteries. The charger uses a dedicated charging profile and automatically switches off once the battery has been fully charged.
An LED indicator provides clear charging status information. Its compact size and low weight make the charger practical for mobile power applications involving boats, fishing equipment and other Rebelcell battery systems.
Key features
- Lithium charger for Rebelcell 12V AV batteries
- Suitable for 12V07 AV, 12V18 AV and 12V30 AV
- Charging voltage: 12.6 ± 0.1 V
- Maximum charge current: 4 A
- Connection: XT60 with XT60-Faston charging cable
- Automatic charging program with cut-off after charging is complete
- LED indication for power and charging status
- Protection against short circuit, reverse polarity and overvoltage
- Compact lightweight design of approx. 0.35 kg
- Suitable for indoor use only
Product specifications
- Brand: Rebelcell
- Article code: LC12V04REUA
- Product type: lithium battery charger
- Suitable for:
- Rebelcell 12V07 AV lithium battery
- Rebelcell 12V18 AV lithium battery
- Rebelcell 12V30 AV lithium battery
- Battery technology: lithium-ion
- AC input: 100-240 VAC, 50/60 Hz
- Charging voltage: 12.6 ± 0.1 V
- Maximum charge current: 4 A
- Power: 50 W
- Charging profile: pre-charge / CC / CV / cut-off
- Connector: XT60 + XT60-Faston charging cable
- Charge status indication: LED
- Minimum battery voltage: 3 V
- Operating temperature: -10 °C to +40 °C
- Dimensions: approx. 125 x 65 x 35 mm
- Weight: approx. 0.35 kg
- Use location: indoor use only
- Waterproof rating: not waterproof
- Warranty: 2 years according to Rebelcell
- Indicative charging times:
- 12V07 AV: 2-3 hours
- 12V18 AV: 5-6 hours
- 12V30 AV: 8-9 hours
- Note: use only with the specified Rebelcell 12V AV lithium batteries
