The Sven VZ-C1 is a compact wired reversing camera for motorhomes, caravans, vans, horse trailers and commercial vehicles. It sends an analogue video image through a cable connection to a compatible Sven monitor.
The camera has a CCD image sensor and a wide 120-degree viewing angle. This provides a clear overview of the area directly behind the vehicle and supports reversing, parking and manoeuvring.
The VZ-C1 operates from a 12 V DC power supply and has an IP68-rated housing. The camera is dust-tight and protected against water, provided the connector and cable connection are installed and sealed correctly.
The integrated night-vision function has a range of approximately 10 metres. A fixed sun visor helps reduce glare, reflections and direct sunlight.
Key features
• Wired reversing camera
• CCD image sensor
• 120-degree viewing angle
• 12 V DC supply voltage
• Dust- and water-resistant IP68 housing
• Night vision up to approximately 10 metres
• Integrated sun visor
• Adjustable mounting bracket
• Four-pin Sven/VZ screw connector
• Compatible with suitable Sven monitors
• Suitable for motorhomes, caravans, vans and commercial vehicles
• Suitable as a reversing or observation camera
