Teltonika FMC800 Plug & Play tracker with 4G LTE Cat 1 connectivity.
Simply plug the device in OBD-II port and start tracking.
Teltonika FMC800 is a Reliable 4G (LTE Cat 1) connection with fallback to 2G (GSM) network.
PRODUCT SPECIFICATIONS
Module
Name: FMC800-QJIB0: Quectel EG915U-EU with Teltonika TM2500
Technology: LTE CAT 1/GSM/GPRS/GNSS/BLUETOOTH® LE
Name: FMC800-QJIB0: Quectel EG915U-EU with Teltonika TM2500
Technology: LTE CAT 1/GSM/GPRS/GNSS/BLUETOOTH® LE
GNSS
GNSS: GPS, GLONASS, GALILEO, BEIDOU, QZSS, AGPS
Receiver: 33 channel
Tracking sensitivity: -165 dBM
Position Accuracy: < 2.5 m CEP
Velocity Accuracy: < 0.1 m/s (within +/- 15% error)
Hot start: < 1
Warm start: < 25 s
Cold start:< 35 s
GNSS: GPS, GLONASS, GALILEO, BEIDOU, QZSS, AGPS
Receiver: 33 channel
Tracking sensitivity: -165 dBM
Position Accuracy: < 2.5 m CEP
Velocity Accuracy: < 0.1 m/s (within +/- 15% error)
Hot start: < 1
Warm start: < 25 s
Cold start:< 35 s
Cellular
2G bands: FMC800-QJIB0: GSM: B2/B3/B5/B8
2G bands: FMC800-QJIB0: GSM: B2/B3/B5/B8
4G LTE bands: FMC800-QJIB0: LTE FDD: B1/B3/B7/B8/B20/B28
Data transfer:
LTE: LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL)
GSM: GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL)
Data support: SMS (TEXT, PDU), Network protocols (TCP, UDP, TLS, MQTT)
Data transfer:
LTE: LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL)
GSM: GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL)
Data support: SMS (TEXT, PDU), Network protocols (TCP, UDP, TLS, MQTT)
Power
Input voltage range: 10 - 30 V DC with overvoltage protection
Internal Back-up battery: 170 mAh Li-Ion battery, 3.7 V (0.63 Wh)
Internal fuse: 3A, 125V
Input voltage range: 10 - 30 V DC with overvoltage protection
Internal Back-up battery: 170 mAh Li-Ion battery, 3.7 V (0.63 Wh)
Internal fuse: 3A, 125V
Bluetooth® Technology
Specification: 4.0 + LE
Specification: 4.0 + LE
Supported peripherals: Temperature and Humidity sensor, Inateck Barcode Scanner, Universal Bluetooth® LE sensors support
Connection: OBDII Socket
