The Fusion Signature five-channel marine amplifier is designed for powerful and efficient onboard audio reproduction. With four channels for speakers and one dedicated subwoofer channel, a single amplifier can support a complete audio zone.
Class-D technology combines high output with efficient power consumption, an important benefit in a 12 V onboard electrical system. The amplifier is designed for marine environments and suitable for fixed installations on boats, tenders and yachts.
Key features
- Five-channel marine audio amplifier
- Signature Series version
- Class-D amplifier technology
- Maximum output: 1600 W
- Designed for speakers and one subwoofer
- Suitable for up to four pairs of speakers and one subwoofer
- 2 Ω stable channel configuration
- Bridgeable channels for higher output configurations
- Corrosion-resistant marine design
- Protected connections and controls behind cover panel
- Suitable for high-quality onboard audio installations
Product specifications
- Brand: Fusion / Garmin
- Article code: 010-01968-00
- Model: SG-DA51600
- Series: Signature Series
- Product type: marine audio amplifier
- Number of channels: 5
- Amplifier class: Class D
- Maximum output: 1600 W
- RMS output at 4 Ω: 4 x 80 W + 1 x 250 W
- RMS output at 2 Ω: 4 x 130 W + 1 x 330 W
- Bridged RMS output at 4 Ω: 2 x 250 W + 1 x 250 W
- Suitable for: speakers and subwoofer
- Maximum listed configuration: up to four speaker pairs and one subwoofer
- Frequency response: 10 Hz - 50 kHz
- Channel load: 2 Ω per channel or 4 Ω bridged
- Power supply: 12 V onboard electrical system application
- Housing: marine design with polished stainless-steel cover panel
- Electronics: conformal-coated circuit boards according to product information
- Dimensions: approx. 300 x 210 x 50 mm
- Application: marine audio installations on boats, tenders and yachts
