The NSR NPT-100 Navtex printer is a compact thermal printer for professional marine applications. It is designed to print messages and reports from NAVTEX receivers, Inmarsat-C systems and other marine electronic equipment.
Because it uses thermal printing, no ink or toner is required. The printer is compact, quiet in operation and suitable for installation on the bridge, near navigation equipment or in a communication console. The NPT-100 includes an RS232 serial port and a parallel port for connection to compatible marine systems.
Key features
- Thermal printer for marine applications
- Suitable for NAVTEX receivers
- Also usable with Inmarsat-C and other marine electronics
- Compact design for onboard use
- Quiet and reliable printing
- No ink or toner required
- Print width: 80 mm
- Resolution: 8 dots/mm
- Long-life print head
- High or low print speed setting
- Interface: RS232 and parallel port
- Suitable for professional navigation and communication equipment
- Practical printer option for NSR NVX-3000 Navtex Receiver
- Not intended as a standard office printer
Product specifications
- Brand: NSR / New Sunrise
- Model: NPT-100
- Product type: thermal printer / Navtex printer
- Printing method: thermal dot line printing
- Printing width: 80 mm
- Resolution: 8 dots/mm
- Dots per line: 640 dots
- Printing speed: high or low selectable
- Print head life: 100 million pulses or more according to specification
- Character matrix: ASCII 16 x 24 dots
- Interface: 1x RS232 serial port
- Additional interface: 1x parallel port
- Adapter input: AC100–240V or AC110/220V, 50–60Hz, depending on version/supplier
- Adapter output: DC 8V ±5%
- Optional: NPS-120 DC/DC converter, 24V DC to 8V DC
- Operating temperature: 0 °C to +40 °C
- Storage temperature: -20 °C to +60 °C
- Dimensions: approx. 66 x 180 x 210 mm
- Weight: approx. 0.5 kg
- Application: NAVTEX, Inmarsat-C, MF/HF, VHF/DSC reporting and marine systems
- Supplied: printer, thermal paper, AC/DC adapter, RS232 connector with cable and manual
