Maximum MDA-110 - LTE MDA-110 - LTE active DVB-T2, Omni Directional 21dB DVB-T antenna
Maximum MDA-110 - LTE active outdoor antenna for reception of FM / DIgitenne / DVB-T and DAB+. It is an active antenna that works on the 5 Volt antenna output of your LED TV, external tuner or with the included 220V and 12V connection. It comes complete with antenna, various screws, two mounts (Hunting/Caravan mount + chassis for on caravan), 12 V PSU, 3 meters of coaxial cable, power inserter (12-24V DC IN to 5V DC OUT).
With Built-in LTE filter.
Maximum has equipped the MDA-110 with a built-in LTE filter, which filters 4G traffic from the digital TV signal. As a result, you won't experience interference from 4G traffic such as cell phones and/or data connections.
Color of product: White. Height: 12 cm, Diameter: 27 cm, Weight: 600 grams.
Features Maximum MDA-110 - LTE MDA-110 - LTE active DVB-T2:
Also suitable for DAB+ and FM
For digital VHF/UHF terrestrial TV stations
Strong plastic construction, UV and salt corrosion resistant
Max. wind load 130 km/h (36 m/s)
Including power supply
Frequency range: UHF : 470-790 MHz, VHF : 47-240 MHz
Gain; UHF 17 dB + / - 3dB , VHF 21 dB + / - 3 dBConnector: F-connector
Power supply: 12 V/230 V
Antenna power: 5 V
Wind load: max wind speed 130 km/h (36 m/s)
Package contents
Max MDA-110 DVB-T2 antenna
Mounting materials for roof, pole and wall
Coaxial cable 3 meters (IEC male-IEC female)
Power inserter
AC/DC adapter
Manual
