The Garmin ECHOMAP UHD2 72cv is a compact 7-inch chartplotter and fishfinder with physical keyed controls.
This product page combines two variants:
• 010-02593-00 – without transducer
• 010-02593-01 – including Garmin GT20-TM transducer
The chartplotter itself is identical for both versions. Only the included transducer differs.
The ECHOMAP UHD2 72cv supports Garmin traditional CHIRP sonar and ClearVü scanning sonar with up to 500 W sonar output.
Built-in WiFi provides compatibility with the Garmin ActiveCaptain app and allows sonar data, waypoints and routes to be shared wirelessly with another compatible ECHOMAP UHD2 chartplotter.
Key features
• 7-inch colour display
• Physical keyed controls
• No touchscreen
• 800 × 480 resolution
• Built-in GPS
• Galileo support
• Traditional CHIRP sonar
• ClearVü scanning sonar
• Up to 500 W sonar output
• WiFi
• Garmin ActiveCaptain
• Garmin Quickdraw Contours
• Garmin Navionics+ support
• Garmin Navionics Vision+ support
• microSD card slot
• IPX7
• Bail or flush mounting
Product specifications
• Brand: Garmin
• Series: ECHOMAP UHD2
• Model: 72cv
• Product type: chartplotter / fishfinder
• Display size: 7 inches
• Display area: approximately 155 × 87 mm
• Display type: WVGA TN
• Resolution: 800 × 480 pixels
• Touchscreen: no
• User interface: keyed
• Dimensions: approximately 232 × 143 × 67 mm
• Weight: approximately 0.7 kg
• Water rating: IPX7
• GPS: yes
• Galileo: yes
• Receiver: 5 Hz
• WiFi: yes
• Garmin ActiveCaptain: yes
• NMEA 2000: no
• NMEA 0183: no
• Garmin Marine Network: no
• microSD slots: 1
• Maximum microSD capacity: 32 GB
• Waypoints: 5,000
• Track points: 50,000
• Saved tracks: 50
• Routes: 100
• Traditional CHIRP: yes
• ClearVü: yes
• SideVü: no
• Sonar output: up to 500 W
• Transducer port: 1x 4-pin
• Input voltage: 9-18 V DC
• Typical current draw at 12 V: approximately 1.0 A
• Maximum current draw at 12 V: approximately 1.5 A
• Maximum power usage: approximately 18 W
Variants
• 010-02593-00 – without transducer – EAN 0753759284640
• 010-02593-01 – with GT20-TM – EAN 0753759284657
GT20-TM specifications
• Traditional sonar: 77/200 kHz
• ClearVü: 455/800 kHz
• Depth measurement: yes
• Water temperature: yes
• Connector: 4-pin
• Installation: transom mount
• SideVü: no
