The Toyotomi 17206051 is an original Extension Flue Pipe size S for compatible Toyotomi FF heaters.
It is intended for installations where the standard balanced flue is too short for a thicker exterior wall. The S version accommodates wall thicknesses from 320 to 420 mm.
Specifications:
- Brand: Toyotomi
- Product type: extension flue pipe
- Version: S / Small
- Part number: 17206051
- EAN: 4963505060510
- Suitable wall thickness: 320-420 mm
- Application: Toyotomi FF heaters
- Installation: horizontal exterior wall penetration
- Function: extension of balanced flue system
- Genuine Toyotomi installation component
Compatibility includes:
- Toyotomi FF-V30
- Toyotomi FF-V30T
- Toyotomi FF-55
- Toyotomi FF-55T
- Toyotomi FF-95
Available wall-thickness versions:
- Short 17206085: 70-130 mm
- Standard 17224296: 130-320 mm
- S 17206051: 320-420 mm
- M 17206052: 420-520 mm
- L 17206053: 520-620 mm
Important:
- Designed for compatible Toyotomi FF installations
- Not intended as a universal heater flue
- Not intended for vertical flue installation
- Check actual wall thickness before ordering
